The SawStop Jobsite Saw Pro delivers durability, innovation and precision with a design that’s built for the worksite. Take the world’s safest saw wherever the job takes you.Included Items
(1) Collapsible Rolling Cart
(1) High/Low T-Style Fence W/Ergolock
(1) Miter Gauge
(1) Jss Active Dust Collection Blade Guard
(1) Riving Knife
(2) Blade Wrenches
(1) Push Stick
(1) 10” Blade
(1) Standard Brake Cartridge
(1) User’S Guide
(1) Assembly Instructions Poster
(1) Hardware Pack
(1) 3mm Hex Key
(1) 4mm Hex Key
(1) 5mm Hex Key
| Model Option | 10" Jobsite Saw PRO: 1.5HP (4.0HP MAX), 120VAC, 60Hz. Inc. jobsite mobile cart & high/low fence system |
| Motor Configuration | 120 VAC 60 Hz, Universal |
| Amperage | 15A |
| Motor Peak HP | 4 HP |
| Motor Continuous HP | 1.5 HP |
| No Load RPM | 4,000 |
| Restart Protection | Yes |
| Cord Length | 116" |
| Saw Dimensions without Cart | 31-3/4" W x 28-3/4" D x 15-1/2" H |
| Saw Dimensions with Open Cart | 48" W x 29" D x 36" H |
| Saw Dimensions with Closed Cart (on End) | 26-1/2" W x 29" D x 45" H |
| Table Dimensions (Retracted) | 31-1/4" W x 24-5/8" D |
| Table Dimensions (Extended) | 43-5/16" W x 24-5/8" D |
| Shipping Dimensions | 32" W x 43" D x 26" H |
| Weight (Saw Only) | 84 lbs |
| Weight (with Cart) | 113 lbs |
| Shipping Weight (with Cart) | 137 lbs |
| Blade Diameter | 10" |
| Dado Diameter | 8" |
| Bevel Angle Range | -1 to 46 |
| Blade Tilt | Left |
| Max. Depth of Cut, Blade at 0º | 3-1/8" |
| Max. Depth of Cut, Blade at 45º | 2-1/8" |
| Max. Rip Right of Blade (Extended) | 25-1/2" |
| Max. Rip Left of Blade | 9-3/4" |
| Arbor Diameter at Blade | 5/8" |
| Main Bearing Size | 62mm OD x 30mm ID x 16mm W |
| Second Bearing Size | 52mm OD x 25mm ID x 15mm W |
| Table in Front of Blade (Max Elev) | 7-7/8" |
| Table Behind Blade (Max Elev) | 7-3/8" |
| Miter Slots T-shaped Dimensions | .754" W x .413" D; "T" .956" W x .157" THK |
| Dust Collection Port Diameter | 2-9/16" Outside, 2-1/4" Inside |
| Riving Knife/Splitter Thickness | 2.3mm (.090") |
| Active Dust Collection Blade Guard | polycarbonate, extends 1" right of blade |
| Blade Guard (Dust Collection) Port Diameter | 1-11/16" Outside, 1-3/8" Inside |
| Hand Wheel | Effective diameter 6.3" |
| Belts | Poly-V static dissipative belt |
